Periodic Reporting for period 1 - GoldTrace (GoldTrace: tracking the origin and transport of gold beneath seafloor arc volcanoes)
Reporting period: 2018-09-01 to 2019-08-31
Metals are key to master the world’s transitions into a carbon-neutral economy. The discovery of land-based large deposits of strategic metal -such as copper and gold- is becoming increasingly difficult and explorers start to focus on the deep sea to ensure security of supply. We know that high-grade copper, silver and gold deposits on land are often associated with seafloor arc volcanism. Yet little is known about petrogenetic processes that controls the copper, silver and gold budget beneath volcanic arcs. The intra-oceanic Kermadec arc offshore New Zealand is arguably the world’s most hydrothermally active volcanic arc. To isolate slab versus overriding mantle (wedge) contributions, we present high-precision Au, Ag and Cu analyses together with other geochemical data from 65 submarine glasses recovered from the length of the Kermadec arc. The data reveal that Au, Ag and Cu contents (e.g. Au <1 to 15 ppb) are always highest in glasses with the a composition indicative of their origin from the most depleted sub-arc mantle. Therefore, high degrees of partial melting and high temperatures are the defining petrogenetic parameters to produce copper, silver and gold-rich magmas. Re and Pt are also mainly controlled by sub-arc processes whereas other metals, such as Mo, Tl, W, Bi and As are dominated by the influx from a subducting slab component (e.g. sediments and altered oceanic crust). The GoldTrace project therefore helps to define petrogenetic parameters that the formation of metal-rich magmas, pre-requisite to form high-grade volcanic hosted mineralization on the seabed.
Work performed from the beginning of the project to the end of the period covered by the report and main results achieved so far
To test whether the Cu, Ag and Au (and other metal) budget in arc lavas is controlled by the composition and thickness of the subducting slab we selected 65 glass samples from 17 Kermadec arc front volcanoes and several sites from the Havre Trough back-arc immediately west of the Kermadec arc front (e.g. Caratori Tontini et al., 2019). The samples that span ~1200 arc km and from arc front volcanoes, located above and to the north from the subducting Hikurangi Plateau (Fig. 1), were collected over the course of 20 years using the RVs Tangaroa and Sonne and the manned submersible Pisces V. Based on the new data produced during the GoldTrace project we developed a new model to explain what processes control Cu, Ag and Au beneath arc lavas (see details in WP 3). In this contributing we were able to link Cu, Ag and Au contents to temperature estimates and mantle depletion, requiring high degrees of partial melting of the Kermadec sub-arc mantle. Although the contribution This work is currently in review at Nature Geoscience. A second manuscript focussing on the behaviour of other mildly to highly chalcophile to metals (As, Mo, W, Tl, Re, Pt) is in preparation. Through this work it becomes more apparent how different individual metals behave during sub-arc magmatic processes and what the source of them are. A third publication about metal content and their transport to the seabed beneath Brothers volcano, Kermadec arc, is planned but has not commenced yet. These contributions will help to define regions on the seabed that preferably host Cu, Ag and Au-rich lavas on the seabed. Because it has been shown that a link exists between Cu, Ag and Au contents in arc lavas and the Cu, Ag and Au-grade of related mineralisation (Park et al., 2019). The results from our study will therefore help to develop vectors to guide explorers in their quest of discovering high grade ore deposits.
