Periodic Reporting for period 1 - Smartlifts (Making Lifts Smart for More Connected and Intelligent Services.)
Reporting period: 2015-02-01 to 2015-04-30
Summary of the context and overall objectives of the project
The current innovation business project was submitted and approved on September 2014 as a SME Instrument (SMEI) Phase 1 with a total score of 13.41 (Impact: 4.45 / Excellence: 4.44 /Implementation: 4.52). After the execution of Phase 1, during three months, all the objectives has been achieved as scheduled.
Merak SL Telecomunicacions i Sistemes wants to completely digitalise a central means of mass transportation: lifts. Concentrating their technological advantages; such as the digitalisation of signals in the design of high speed net connection and the integration of advanced features into a single terminal, into one concept SmartLifts. It consists of a software –hardware service containing a gateway, audios modules, sensors and a management platform which synthesize connectivity and security within lifts. Thus, increasing safety and reducing maintenance cost and also shifting from the conventional lift emergency systems based in landline telephone communication towards a smarter lifts emergency system.
SmartLifts will allow the lift industry to migrate from existing fleet of analogue emergency telephone modules to a more versatile and efficient solution to incorporate a new technological culture in the lift fleet management and create a safer experience for millions of people who use lifts on a daily basis. Over the last three months Merak has designed a strong business plan, based in a SaaS maintenance service that will allow the remotely control of a company´s lifts fleet and improve all services provided by a lift maintenance company.
The economic feasibility of SmartElevator has also been widely analysed and the results show that the business model is viable (EBITDA margin = 18% after 6 years in the market).
It is important to mention that after market research and examination of international and national trademarks, the name of Smartlift was changed to SmartElevator. Smartlifts, in plural, was already registered, in the Spanish and European harmonization offices for the internal market. Smartlifts is the name of a product and a Spanish company, also working in the vertical transportation industry. Thus, Merak decided to change the name in order to avoid any intellectual property violations.
The outputs of each one of the tasks demonstrate that SmartElevator management communication suite is free to operate. During the execution of this action we have been able to compare our solutions with others. Similarly, we have studied similar hardware-software solutions in order to have them as references for further development and commercialization activities. That said our hardware/software service still shows to be innovative and relevant in the current market with room for development in order to offer a fully tele-diagnostic of the 74 (70 in case of certain EU countries) hazards that could affect lifts performance.
Furthermore, a work plan for future steps has been developed, which involves the presentation of a Phase II proposal. The first stage of Phase II is devoted to carry out the modifications needed in the existing cabin audio electronics to connect it to the new set of sensors and the smart camera, and to study options to enable high speed net connection between the cabin and the control panel. In parallel, the existing software will be further developed to store all the incidences, plus a mobile app to control in-situ repairs. When all the systems have been developed, the new lift control and alarm system will be integrated and pilot tested will be carried out in at least two different lift environments (residential and business buildings).
Merak SL Telecomunicacions i Sistemes wants to completely digitalise a central means of mass transportation: lifts. Concentrating their technological advantages; such as the digitalisation of signals in the design of high speed net connection and the integration of advanced features into a single terminal, into one concept SmartLifts. It consists of a software –hardware service containing a gateway, audios modules, sensors and a management platform which synthesize connectivity and security within lifts. Thus, increasing safety and reducing maintenance cost and also shifting from the conventional lift emergency systems based in landline telephone communication towards a smarter lifts emergency system.
SmartLifts will allow the lift industry to migrate from existing fleet of analogue emergency telephone modules to a more versatile and efficient solution to incorporate a new technological culture in the lift fleet management and create a safer experience for millions of people who use lifts on a daily basis. Over the last three months Merak has designed a strong business plan, based in a SaaS maintenance service that will allow the remotely control of a company´s lifts fleet and improve all services provided by a lift maintenance company.
The economic feasibility of SmartElevator has also been widely analysed and the results show that the business model is viable (EBITDA margin = 18% after 6 years in the market).
It is important to mention that after market research and examination of international and national trademarks, the name of Smartlift was changed to SmartElevator. Smartlifts, in plural, was already registered, in the Spanish and European harmonization offices for the internal market. Smartlifts is the name of a product and a Spanish company, also working in the vertical transportation industry. Thus, Merak decided to change the name in order to avoid any intellectual property violations.
The outputs of each one of the tasks demonstrate that SmartElevator management communication suite is free to operate. During the execution of this action we have been able to compare our solutions with others. Similarly, we have studied similar hardware-software solutions in order to have them as references for further development and commercialization activities. That said our hardware/software service still shows to be innovative and relevant in the current market with room for development in order to offer a fully tele-diagnostic of the 74 (70 in case of certain EU countries) hazards that could affect lifts performance.
Furthermore, a work plan for future steps has been developed, which involves the presentation of a Phase II proposal. The first stage of Phase II is devoted to carry out the modifications needed in the existing cabin audio electronics to connect it to the new set of sensors and the smart camera, and to study options to enable high speed net connection between the cabin and the control panel. In parallel, the existing software will be further developed to store all the incidences, plus a mobile app to control in-situ repairs. When all the systems have been developed, the new lift control and alarm system will be integrated and pilot tested will be carried out in at least two different lift environments (residential and business buildings).
Work performed from the beginning of the project to the end of the period covered by the report and main results achieved so far
Overview of the Work done:
The current report is an overview of the work done during the execution of this phase 1. In the proposal five tasks where defined: market assessment, legal framework, business environment, IPR issues and business plan. Each one of this task served for the preparation of a feasibility study, which is the main output of this phase 1 and also is the starting point to prepare a phase 2 proposal.
During the execution of phase 1, a refinement of the existing hardware was carried out. Identifying new sensors to the existing hardware to monitor some of hazardous situations mentioned at the SNEL EN 81-80: 2003 European Standard as well as “Recommendation” 95/216/EC. At the moment, SmartElevator is based on an existing prototype that consists of a hardware-software solution with two main parts: a hand-free audio module that is installed in the elevator car and a module (gateway) incorporating 2G and 3G mobile technology that is installed in the elevator machine room. The future hand-free audio module could also be enabled with high speed net connection, thus improving data transfer between the cabin and the control panel. Currently, the connection to the audio module is performed by digital audio through CAN-BUS (controller area network) and the gateway offer connectivity to manoeuvre through standard data interfaces for remote telediognosis through M2M technology. The software solution is based on an open source web platform.
Figure 1 shows the basic functioning of the existing prototype, which is composed by the following steps:
Merak´s software (Figure 2) has been further developed taking into account other software solutions offered by competitors and the sensors that the new hardware will include. Based on the competition, key market applications were defined and target market was identified. The SmartElevator service will predominately target small and medium lifts service providers in Spain and open up to other European countries in the coming years. Risks such as; market resistance, product misinterpretation, strong market diversification and changes in legislation, were identified and a contingency plans were designed. Regarding IPR issues, a trademark registration search was carried out and identified that Smartlift was already an existing European product and brand. Therefore, the name of this hardware-software solution was changed to SmartElevator. Lastly, an updated business plan, as well as detailed work plan for phase 2 execution has been created.
1.1 Market Assessment
Throughout the last 20 years, Merak has been dedicating it’s time to design useful and safe telecommunication systems for the lift industry, producing reliable and technological advanced products that are accessible to everyone. In emergency situations, like in case of entrapment, Merak devices have always performed impeccably. From this accumulated experience, in the next 10 years we are getting ready to make a qualitative leap forward: Merak aims at becoming a strong European provider for intelligent and thorough lift communication services that contribute efficiently to the management of lift fleets and guarantee an optimal end-to-end service of medium and small maintenance companies to their clients.
Currently, Merak has around 15 strong competitors in Europe, from which, four are strong worldwide lift manufacturers: ThyssenKrupp, Otis, Kone and Schindler. To be able to compete with the large lift manufacturers, now moving towards the tertiary sector, Merak will need to offer a cost-effective and interoperable service to differentiate itself from these strong market actors. Moreover, Merak´s target market is small and medium companies, instead of large corporation buildings, which are lift manufacturers main clients. Merak´s clients will be small and medium maintenance companies that will offer Merak´s SaaS solution, thus allowing them to provide a cheaper and more effective maintenance and monitoring service for their clients´ lift fleets. Merak is targeting small and medium companies to offer a more customised and personalised service.
Merak has other competitors: Avire-Memco (UK), 2N (Czech Republic), Esse-TI (Italy), Peters Research (UK), Safeline (Sweden) and MicroKey (Spain) that offer digitalisation of several features to tele-monitor lifts performance and maintenance. Most of them offer a hardware/software solution, except of Peters Research which offers just a specialist maintenance software, in which information on the lift fleet performance can be tracked and assessed. In figure 3, the ten different features that the SmartElevator service will monitor and assess are shown, also a comparison of the different products/service feautures provided by Merak´s competitors is provided. A Yes means this company´s product has that concrete feature, a No indicates that their service/product doesn’t have the concerned feature and n/a means non-accessible meaning this information could not be found. The most unusual feature that Merak is offering, is the time of reaction in case of lift entrapment or breakdown. This service feature is one of Merak´s areas of expertise, having specialised in emergency communications for the past 15 years. Additionally, it also visible that Merak offers the most integrated service as none of the other competitors offer the digitalisation of all the below features.
Merak´s hardware/software solution aims at fighting restrictions placed by lift manufactures and other lift service providers, as this product doesn’t restrict its use to selective lifts but aims at establishing an interoperable service that can be implemented in any lift. To have a strong impact and acknowledgement in the vertical transportation sector and allow new and current customers to understand this new interoperable service, Merak will improve the branding of SmartElevator by designing an appealing visual identity and maximising its presence in social media and news channels.
This smart and breakthrough technology will enable the democratisation and transparency of the vertical industry sector as it aims to simplify operating systems of lift hardware and facilitate data collecting and sharing through a specialist software solution. Increasing the level of interoperability between the systems of different suppliers and service companies, Merak will differentiate itself from all competitors thus avoiding maintenance companies to cope with different performing systems but just remotely control all lift fleet independently from its manufacturer or provider.
1.2 Legal Framework study
From a regulatory perspective, SmartElevator will need to comply with existing European and national directives. The three European directives that need to be taking into consideration for the maintenance and safety requirement of lifts are: the first Lifts Directive/95/16/EC, the upcoming Lift Directive 2014/33/EU and the Machine Directive 2006/42/EC. European lift safety standards detail safety rules for various types of lift and also cover different aspects of lifts construction and operation. All safety and maintenance requirement need to be taking into account when launching a lift communication service into the market.
EU Legal Framework
European legislation for lifts has been predominantly based on the Lifts Directive/95/16/EC which establishes European legal requirements for the design, construction, installation and placing on the market of new lifts. National legislation of EU member states relating to lift safety has been replaced by the European Lift Directive. The EC and its partners, including European Elevator Association (EEA) and European Lift & Lift Component Association (EFLA) at the time, decided to add a short one page “Recommendation” 95/216/EC with the 10 following recommendations to make existing lifts safe.
1.Car doors to be fitted and a floor-level indicator to be fitted inside the car.
2.The car suspension cables to be inspected and possibly replaced.
3.The stop controls to be modified in order to achieve a high degree of precision in the stopping level of the car and a gradual deceleration.
4.Make the controls in both the cars and lift wells intelligible and usable by unaccompanied disabled persons.
5.Fit human- or animal-presence detectors to the automatic doors.
6.For lifts which travel faster than 0,6 m/s, fit a parachute system allowing them to decelerate smoothly when stopping. Modify the alarm systems to establish a permanent link with a high-speed breakdown service.
7.Eliminate any asbestos in the braking systems, where this exists.
8.Fit a device preventing uncontrolled movements towards the top of the car.
9.Provide cars with emergency lighting that operates in the event of a main power supply failure. It must operate for long enough to enable the rescue services to intervene in a normal manner. The installation must also enable the alarm system provided for in item 7 to function.
The Lifts Directive objectives are: to permit the free movement of lifts and safety components for lifts within the internal market and to ensure that these products provide a high level of protection of the health and safety of people. The Lifts Directive entered into force on 1st July 1999. It has been recently amended by the revised Machinery Directive 2006/42/EC, which is applicable since 29 December 2009. The main aim for the revision was to clarify the borderline between the scopes of both Directives.
The directive offers lift manufacturers greater design freedom. It’s now possible to choose alternatives to the possibilities offered by the harmonized European standards. But any alternatives chosen must meet the fundamental health and safety requirements laid down by the directive. Conformity with these requirements must be demonstrated by a risk assessment.
In case of lifts manufacturer and safety components providers, they must establish that products meet the requirements stipulated by the directive. They can do this by using one of several conformity procedures. Depending on the procedure chosen, they and/or a designated certification organization (Notified Body) can take the required actions. If they choose to perform these actions yourself, they must work with a quality assurance system which has been certified by a Notified Body. This system must incorporate the requirements laid down by the directive. They can choose the conformity procedure which best suits their needs.
The Machinery Directive EU
On 29 December 2009, the new Machinery Directive 2006/42/EC came into force. This directive replaces the old Machinery Directive 98/37/EC. There is no transition period. The directive can also be important for lift manufacturers. The Lift Directive is distinct from the Machinery Directive and lifts must meet both directives.
What does this new directive mean in broad terms for lifts and related equipment? The new Machinery Directive was introduced because the old one was no longer in line with the so-called ‘new approach’ applied to all directives. In addition, a number of products needed to be added to the directive’s application areas in order to clarify certain matters.
It was also clear that the wording of the old directive needed to be improved and that in some cases, like lifts, the distinction between directives should be clarified. The ultimate goal of the revised directive is to maintain Europe’s competitive position in the global market. A noticeable change is a limit to the validity period of a product certificate which is now five years.
One of the harmonized standards covered by the Machinery Directive is EN115-1:2008 Safety of Escalators and Moving Walks - Part 1: Construction and Installation. This standard explains the construction and installation of escalators and moving walks. It addresses significant hazards, safety requirements, protective measures, test reports and information related to safety. The standard’s appendices include illustrations and tables that further explain various concepts.
The new Lifts Directive coming to force in 2016
On 29 March 2014 the new Lifts Directive 2014/33/EU was published. This directive comes into force in every European member state on 20th April 2016.
The changes are mainly legal and the aim is to bring the directive more in line with the so-called ‘new legislative framework’, which establishes the general terms and conditions regarding accreditation, more stringent market surveillance and conformity procedures. The new directive also includes amendments to the current directive. The new directive does not affect previously issued EC type certificates. These remain valid as long as the certified products and the accompanying technology remain unchanged.
What changes with the new Lift Directive?
•The provision against unintended car movement, in directive jargon the UCMP, is not currently a safety component, but it is in the new directive. An EU type certificate will soon be needed for this, along with an EU conformity statement and a CE mark.
•EC changes to EU. In the new directive, the same designation applies to all European countries.
•With a unit verification, the certificate of conformity will soon become a conformity certificate.
•The CE declaration, issued when a lift goes into service, will soon be called an ‘EU declaration of conformity’.
•More identification information for product marking will have to be added to the lift and safety components.
•The only technical change is that with a unit verification a load test is mandatory throughout Europe
European Lift safety standards
Moreover, there are European standards supporting EU legislation which address other issues of interest to the lift service providers. In 2003, the European Committee of Standardization (CEN) added to its well-known European Standard for new lifts, EN 81-80: 2003 (SNEL, the safety norm for existing lifts) as part of the process of European legal harmonization. EN 81-80:2003, Safety rules for the construction and installation of lifts – Existing lifts – Part 80: Rules for the improvement of safety of existing passenger and goods passenger lifts, categorizes various hazards and hazardous situations, each of which has been analysed by a risk assessment.
It then provides a list of corrective actions to improve safety progressively. The lift should be audited against a checklist of more than 70 items (74 in Western Europe but several more in Central & Eastern European member states). The identification of the hazardous situation can be carried out in the course of any periodical survey or special examination on a given installation, but only technically competent and sufficiently trained persons should be allowed to carry out these examinations. However, this can be subjected to national regulations.
Once the weak points of the installation have been identified through this pro-active assessment or safety audit, improvements can be made (if necessary) by a stepwise upgrading which can naturally be combined with any modernization being carried out. In addition, preventive maintenance and repairs are a necessary ongoing process.
Members of the European Committee for Standardization are bound to give all European Standard the status of national standard without any alteration. Thus, SmartElevator aims to simplify the identification of the hazards named in the EN 81-80:2003 providing a smart interoperable lift emergency communications suite and contribute to the harmonization and surveillance of the lift market in Europe.
Additionally, the European Lift Association (ELA) considers that the SNEL is a powerful tool that will soon show its impact in Europe and will help as a benchmark for other countries. Even though, the application of EN 81-80 will vary by country, including the 74 identified risks, in the content and programming, about 75% of existing lifts wi
ll be affected by SNEL in the next 5-10 years.
Other safety standard that need to be taking into consideration when launching SmartElevator are the following:
•EN 81-21: Safety rules for the construction and installation of lifts in existing buildings. This European Standard specifies the safety rules related to new passenger and goods/passenger lifts permanently installed in existing buildings where in some circumstances due to limitations enforced by building constraints, some requirements of EN 81-1 and EN 81-2 cannot be met.
•EN81-28: Remote Alarms for Passenger and Passenger and Goods lifts.This standard covers remote alarm systems in passenger and goods lifts. It addresses significant hazards, safety requirements, protective measures, information to be provided, tests, markings and notices to be posted.
•EN81-70: Accessibility of Lifts for Persons including Persons with Disability. This standard covers accessibility of lifts for able-bodied and disabled people. It addresses significant hazards and barriers, safety requirements, protective measures and information for users.
•EN81-72: Firefighters Lifts. This standard covers firefighters’ lifts. It addresses significant hazards, safety requirements, protective measures, significance of the landing door and access to facilities using the fire service access level.
•EN81-73: Behaviour of Lifts in the Event of Fire. This standard covers the behaviour of lifts in the event of a fire. It addresses significant hazards, safety requirements, protective measures and information for users.
•EN 81-77: Lifts subject to seismic conditions. This European Standard specifies the special provisions and safety rules for passenger and goods passenger lifts where these lifts are permanently installed in buildings that are in compliance with EN 1998-1 (Eurocode 8). This standard defines additional requirements to EN 81-1 and EN 81-2. It applies to new passenger lifts and goods passenger lifts.
1.3 Business Environment
External Factors Affecting the Project
1. Lack of interoperability in the sector: Making sure a lift never breaks down requires access to lift data related to its activity, that most of the time isn’t accessible to lift owners and maintenance companies. Data captured by the lift hardware and/or available through the use of sensors can be process in advance by maintenance companies if these have access to this data remotely. In an ideal world, lifts hardware should have the same characteristics and the captured data should be processed by a similar software. In the vertical transportation sector nowadays, four important market players aim at developing M2M solutions and IoT improvements that are exceptional to their lifts. Meaning that they aim to have safe and cost-effective lifts that are just manufactured by themselves. ThyssenKrupp group is a clear example of this type of restrictive practices, having developed a system that will monitor about 60% of its lifts worldwide. A hardware/software solution that will benefit the user of its lifts but restricting maintenance companies work in ThyssenKrupp group lifts. Maintenance companies will need to adapt to ThyssenKrupp communication solution while working with other software to monitor their non- ThyssenKrupp lifts.
2. Mobility trend and urbanisation: While urbanization, driven by a shift towards industry and services from a largely agrarian society, first transformed developed countries, the phenomenon started to shape the future of the developing world in the 1950s. Continuing population growth and urbanisation are projected to add 2.5 billion people to the world´s urban population by 2050. Moreover, people tend to live more vertically than ever before and need safe and smart devices to have tranquil journey to their home and/or work floors.
Thus, lifts should stop being isolated installations and become more connected. To keep lifts running is a full-time business that needs simplification and cost effective solutions. It is not just to match demand of new buildings in the fast-growing nations such as Turkey, China and India but also to match the needs of smart cities trend that is present in Europe and important to become an even more competitive region.
3. The increasing importance of safety: Tightened regulations will apply to building owners, housing companies and other lifts operators from June 2015 to ensure safety within their lifts. The most important changes: lifts will be subject to stricter checks. Technically outdated lifts will have to be adjusted to the operating conditions and an emergency plan will need to be drawn up, opening a great opportunity for Merak´s hardware/software solution to enter certain markets. Especially Germany where a new version of the Operational Safety Ordinance was passed by the German Bundesrat and Bundestag, which regulates the operation of lifts in Germany. If the technical requirements increase over time, the need for modernisation will be pointed out to the operators by the national inspectors. The lift then will then have to be modernised – even if it runs without any problems. Furthermore, operators are expressly obliged to equip their lifts with modern emergency call systems by the end of 2020. As a result, building owners and housing companies are facing considerable investments in the near future as many lifts around Europe lack of modern emergency call systems.
4. Concern for the environment: Europe has ambitious goals in terms of reduction of CO2 emissions, energy efficiency improvement and independence for its energy supply. Buildings consume approximately 40 percent of the world’s energy, and elevators can account between two and 10 percent of the energy consumption of an individual building.
The lift industry can play a vital role in helping to counter climate change and its negative effects by providing innovative solutions that help to reduce the energy consumption of buildings. The demand for energy-efficient solutions for moving people in and between buildings is driven by voluntary sustainability ratings and European/national green building ratings. These are becoming more common and are on increasing importance to our customers. Sustainable urban building refers to building practices that improve energy efficiency, use sustainable materials and reduce a building’s negative impacts on human health and the environment. To apply these green practices a group of build sector industrialists, architects and builders have founded a new association: the European Alliance of Companies for energy efficiency in Buildings (EuroACE) which aim is to make policy- makers at European level aware of the benefits that a policy focused on the European construction sector could have.
Analysis of Risks, Opportunities and Threats
Opportunities: As previously mentioned, a hardware/software communication suite will add a high level of security and cost efficiency to all market segments but especially to small and medium maintenance companies. It will also be tailored to specific needs of the customers, software features could be added depending on the extent of sophistication needed for the remote monitoring of their lift fleet. Notwithstanding, SmartElevators is aiming at provoking an impact in the residential and tertiary market sector where Merak has already existing customers. These two market sector are more likely to conduct a cost benefit analysis before hiring any type of service for their lift instead of directly going to big market players.
The demand for security is propelling with respect to the advanced and more sophisticated technology being introduced in the market. Organizations are more attentive to equip themselves for such threats and need to safeguard their properties. Demand for energy efficient solutions, enhanced security, and improving the standards of the individuals have led to the development of the global smart elevator market. Energy efficiency and centralized controls are the driving factors in global elevator automation market. Therefore, it is safe to say that SmartElevators has a place in the growing smart elevator market.
A well maintained elevator lasts for around 20 years or we can say it is an average life of an elevator. After a stipulated time frame, upgrading an already installed elevators-system is a must – be it due to statutory requirements for increasing handling capacity or comfort, saving energy costs. Updating controllers, communication panel, drives, cabins, doors, lightening and sensors and other and innovative operating and display elements with new technologies will enhance elevators’ life, saves energy and power, improved usability for people with special needs.
Translated into use cases applied to the tertiary sector, during the last months, we have conducted a market research with Merak´s current customers which have identified the opportunities that this new and smart M2M technology will have in their daily use of lifts. (More information can be found in D1.1 Feasibility Study)
The opportunities identified were:
•Improvement in the lift maintenance services due to the immediate access to lift information
•Greater control of entrapment situation as users can locate lift technician/ Less panic attacks
•A useful management and communication solution
Risks: The constant change of European regulatory requirements around the lift industry sometimes impedes the return in the investments made by lift service providers when launching a new product. New cases and hazardous situation are found constantly by lift users and service provider that are addressed by legislators by providing more restrictive instructions of lift usage and maintenance.
Due to the changing nature of the European and national regulation within the vertical transportation industry, Merak decided to join the Spanish Association for Standardisation and Certification and it’s the process of being accepted in the European Committee for Standardisation. Thus, Merak is able to better assess the new launch of a product into the market. The lifespan of the product in the market and the investment returns are calculated having present future regulations at the national and international level.
Notwithstanding, in some cases regulations are implemented fairly quickly due to a new hazard situation that needs immediate attention or a system outbreak that might affect a large number of lifts in operation.
Threats: There are several competitors with products that are similar to SmartElevator. Moreover, important market players such as OTIS and ThyssenKrupp could find some of the features of SmartElevator interesting and suitable for their remote lift management services and smart services and thus, integrate these features and new characteristics to their services and products.
While big manufacturers like Schindler have grown by concentrating on installation, they have lately pushed harder in the service business. As construction decreased the first years of the 21st century and investment in older buildings shrank, property owners started to modernize their elevators and lift manufacturers saw an opportunity for business diversification.
Lift manufacturers companies are mayor market players and are established in every single country with a large lift fleet and competitive lift management services, therefore it will be highly difficult to stop them from replicate Merak´s product. Notwithstanding, the target market selected by Merak needs flexibility and customer proximity plus demand is moving towards the specification of ever more complex packages involving lifts from different manufacturers.
Another important threat for SmartElevator to become an interoperable solution for the remote management of lifts is the aggressive marketing campaigns of the big four manufacturers as well as their insistent stance towards the acquisition of maintenance contracts for third-party installations.
Forces Affecting the Market (Figure 4: Porter graph on forces affecting Merak´s business strategy)
The most relevant force affecting the vertical transportation industry is the competition. As mentioned before, this industry is concentrated in the hands of four big players. Lift manufacturers limit the access to innovative European SMEs by producing software and hardware exclusive to their lifts, thus neglecting the change of interoperability in this sector. Most of the sales of lift manufactures come from maintaining and modernizing their lifts offering a competitive and up-to-date technological services to building owners and large companies.
Additionally, this market is affected by a changing regulation scheme. Safety concerns are an important aspect of this industry, and legislators tend to revise standards and regulatory requirements often. These changes in regulation require market players to adjust their product and revise market strategies which cost them time and resources. Lift manufacturers are not very affected by these changes in regulation as they influence directly decision taken by the regulatory agencies. However, every new European standard to be implement by lift service providers requires, at least, time to process the information internally and also in some cases an investment to comply and address to this regulatory request.
There are also other forces affecting the lift market such as:
•Customers’ unwillingness to change products and services as it entails upfront costs
•Large number of suppliers, not just four big lift manufacturers but a large number of SMEs providing services to lift owners and lift maintenance companies
•Uniqueness versus interoperability, how to provide a unique service/product that will not limit your operability in certain elevators.
1.4 IPR Issues
Trademark Registration
The visual identity plays a significant role in the way a product is introduced to its public or targeted audience. The product has to be visual attractive and have a name that can be easily remembered that’s why Smartlift was chosen firstly. However, after large research and competition analysis it was found that Smartlifts (in plural) was the name of an existing product as well as the company´s name. Trademarks are concerned with brand identity – they can be distinctive words, marks or other features, the purpose of which is to establish, in the mind of the customer, a link between the particular product or service and the company.
As mentioned above, Smartlifts was not just a registered product but also the name of the company that launch this product to the market. In their case, it is easy to relate their product to their company as it has the same name. It is however a bit risky as the whole reputation of the company can be impaired if they product is not a success. A trademark can be a valuable business asset, have come to represent not only actual goods and services, but also the reputation of the business. In the case of Merak, a change in name was decided to differentiate its product from the existing ones in the Spanish and international market, now the product is called SmartElevator. The figurative mark is still in development but a few suggestions can be seen at the end of this section.
A trademark is how the costumer identify a company or a product and differentiates each products from everyone else’s and encapsulates each company values, since is part of a company intellectual property and is crucial to each company success as a business.
In that sense, trademarks are signs used in trade to identify products. In the framework of intellectual property law trademarks are practical little items.
It is possible to register from word marks (a word mark is representing using word letter, numbers or any other character that can be typed); figurative mark (a figurative mark is represented using pictures, graphics or images); figurat
ive mark
